Hydraulic oil Filter Element
PartnerFilter can replaces HYDAC,PARKER,FILTREC,INTERNORMEN,TAISEI KOGYO,MAHLE,ARGO,LEMMIN,REXORTH,etc,brands hydraulic oil filters,contact us.
|
|
|
Brand:PartnerFilter
Model: 0050S125W
Type: Oil Filter Cartridge
Bypass: No
Micron: 125μm
Collapse:14.5psid
Filter material: Wire Mesh
Sizes: OD2.52”*L5.47”
End Caps: Aluminum
Center Tube: Corrosion Resistant Steel
Series: 0015 S 075 W /-B0.2, 0015 S 125 W more
|
|
PartnerFilter makes the Hydac suction oil filter strainer 0050S125W replacementand the filter is designed to meet or exceed the quality and performance of original Hydac filtersensuring superior filtration performance and long-lasting durability.
|
|
|
|
|
|
Brand:PartnerFilter
Model:K3.1370-76
Micron:10μm
By-pass:Yes
Filter material:Fiberglass
Sizes:OD147*L707mm
End Caps:Steel
Center Tube:Corrosion Resistant Steel
Series:K3.1034-52,K3.1370-66 more
|
|
The hydraulic oil filter element K3.1370-76 is used as an oil return filter in the hydraulic system to filter out the parts in the hydraulic system.It is installed on the top of the tank,the cylinder is partially immersed in the tank,and the valves are arranged on the side.The diffuser and filter element contaminate and block the transmitter and other devices.
|
|
|
|
|
|
Brand: PartnerFilter
Model: 0330R010ON
Filtration precision: 10um
Filter media: hydraulic oil, lubricating oil
Working Pressure: 500 PSI
Working temperature: -10℃-100℃
Filter material: Optimicron®
Sealing material: NBR (nitrile rubber)
Series: 0330R010ON-V,0330R010ON-KB,0330R020ON-V,0330R020ON-KB more
|
|
0330R010ON Hydac hydraulic filter is used to improve oil cleanliness and equipment operation efficiency. To solve the problem of oil pollution in hydraulic and lubrication systems. 0330R010ON's core function is improve quality and filter out solid particles, colloidal substances, moisture and other impurities in the working medium.
|
|
|
|
|
|
Brand: PartnerFilter
Model: 0550R010ON
Type: oil hydraulic filter
Material: HV fiberglass, Ahistrom filter paper, stainless steel wire mesh
Filter media: hydraulic oil, lubricating oil
Filter accuracy: from 1, 3, 6, 12, 25 …um
Working temperature: -10℃-100℃
Pressure: 1.0Mpa, 2.0Mpa, 16.0Mpa, 21.0Mpa
Application field: hydraulic system, lubrication system
O-Ring: NBR, fluororubber
Series: 0240R010BN3HC,,0210R020BN4HC,0330R010BN3HC,0660R020BN3HC,1300R010BN4HC more
|
|
0550R010ON hydac oil filter is widely used in hydraulic systems, lubrication systems and other fields. Its main function is to filter out impurities and particles in the oil to ensure the cleanliness of the oil, thereby extending the service life of the oil and the normal operation of the system. It is an efficient, stable and reliable filter element.
|
|
|
|
|
|
Brand: PartnerFilter
Model: 0850R010ON
Efficiency: Beta 12{c} >= 1000 (ISO 16889 DFE)
Max Temp (F): 225
Adhesive: Epoxy
End Cap: Anodized Aluminum
Media Type: Microglass supported both sides
Recommended Change Out (psid): 25
Collapse Rating: 250
Series: 0850R010ON/PO, 0850R010BN3HC, 0850R010BN4HC, 0850R010ON more
|
|
0850R010ON hydraulic oil filter is used to protect the hydraulic system, eliminate oil pollution, improve the cleanliness of the oil, reduce wear and blockage of the hydraulic system, and filter out particulate matter in oil. 0850R010ON is made of glass fiber and stainless steel mesh, which has high filtration accuracy and dirt-holding capacity, and improved strength and corrosion resistance.
|
|
|
|
|
|
Brand: PartnerFilter
Model: 636-CAC-PM
Filter Type: Aviation Coalescer Cartridge
Length: 36.0 inches
Outside Diameter: 6.0 inches
Innerside Diameter: 3.5 inches
Filter Material: Multilayer Fiberglass
End Caps: Corrosion Resistant Steel
Center Tube: Corrosion Resistant Steel
|
|
636-CAC-PM coalescing filter is a specialized coalescing filtration mechanical component. 636-CAC-PM coalescer cartridge is mainly used in oil and gas coalescing purification and filtration equipment systems\hydraulic systems to filter out solid particles and colloidal substances in the working medium, effectively Control the pollution degree of the working medium to achieve the effect of purifying the medium.
|
|
|
|
|
|
Brand: PartnerFilter
Model: HC0961FKT18H Pall Hydraulic Filter Cartridge
Filter Type: Pall Hydraulic Oil Cartridge filter
Innerside Diameter: 109mm
Outside Diameter: 183mm
Length: 483mm
Weight: 7.0Kg
Filter micron: 25μm
Seal Material: Viton
End Caps: Corrosion Resistant Steel
Series: HC0961FKT18H,HC8300FKT39H,HC8900FKN8H more
|
|
HC0961FKT18H pall oil hydraulic filter is used in hydraulic systems. It is a specialized coalescing filtration mechanical component.
HC0961FKT18H pall oil hydraulic Filter is used to filter out solid particles and colloidal substances in oil, effectively control the pollution level of the working medium, and achieve the effect of purifying the medium.
|
|
|
|
|
|
