Coalescer and separator
PartnerFilter produces kinds of brands Coaleser Separator Cartridges,PECO,FACET,FAUDI,PARKER&Velcon brands replacement.For detailed filters,contact us
|
|
|
Brand:PartnerFilter
Model: A910303
Series: Turbo-TOC Separator Filter
Length: 743.0 mm
Outer Diameter: 152.4 mm
Inner Diameter: 88.9 mm
Filter Material: Teflon
Seal: Buna-N
Maximum Temperature: 107℃
Micron Rating: 10.00 nominal
Collapse Pressure Rating: 75 PSID
Series: A910203, A910362, A910370, A910415, A910575 more
|
|
A910303 kaydon separator filter is designed for installation in vertical filters/separators. It can filter out solid particles and mechanical impurities, and can also remove emulsified water in the medium through demulsification and coalescence.
|
|
|
|
|
|
Brand: PartnerFilter
Model: NGGC-336 PECO Series
Type: Coalescing Filter
Length: 914.5mm
Outer Diameter: 114.3mm
Inner Diameter: 75mm
Filter Material: Glassfiber
End Caps: Galvanized Steel
Series: NGGC-336, NGGC-336-PL-01 more
|
|
NGGC-336-PL-01 PECO fuel gas coalescer filter is used to remove water, oil vapor and other contaminants from hydraulic fluid compressed air or natural gas lines.For gas filtration and coalescence separation in chemical plants, petrochemical plants, offshore sectors and power stations. High flow rate, low flow resistance and high dust holding capacity.
|
|
|
|
|
|
Brand: PartnerFilter
Model: HC628-01-CSP HILLIARD HILCO Filter
Type: Oil Gas Coalescence Separator Filter
Length: 735 mm
Out Diameter: 155 mm
Micron: 10
Media: Fiberglass
End Caps: Galvanized
Series: HC628-01-CSP HILLIARD HILCO Filter more
|
|
HC628-01-CSP HILLIARD HILCO separator filter main function separate oil-water mixtures, suspensions, emulsions, etc. Filter out solid impurities and coalesce to remove moisture from oil/oil gas. Prevents clogging of orifices in pneumatic controllers and reduces gas engine fouling.
|
|
|
|
|
|
Brand: PartnerFilter
Model: SO-436V5
Type: Oil Fluid Separator Cartridge Filter
Length: 24 inches
Inside Diameter: 3.5 inches
Outside Diameter: 4.5 inches
Carton Weight: 14.5 pounds
Construction: Teflon
Media: TCS
Seal Material: Buna-N
Series:SO-324V5,SO-613GS,SO-633VASN,SO-609V,SO-323V5 more
|
|
SO-436V5 Parker Velcon separator cartridge filter is used to remove coalesced water droplets and solid, hard impurities, clean hydraulic fluid, compressed air or natural gas and other oils. The material uses fiberglass layers, which have a particularly good coalescing effect.
|
|
|
|
|
|
Brand: PartnerFilter
Model: CC3LGA7H13
Type: Liquid Gas Coalescing Cartridge
Length: 29.30 inches
Outer Diameter: 2.80 inches
Inner Diameter: 1.50 inches
Seal Material: fluorine rubber ring, nitrile rubber
Filter Materials: glass fiber filter paper, stainless steel sintered mesh
Working Medium: hydraulic oil, emulsion, water-ethylene glycol etc
Series: CC3LG02H13, CC3LGA7H13, CC05LGH13, CC3LGB7H13more
|
|
CC3LGA7H13 liquid gas coalescing cartridge filter is used to oil and gas separator, hydraulic liquid fuel system. Separate oil-water mixtures, emulsions, suspensions, etc. Clean hydraulic fluids, compressed air or natural gas and other oils. Corrosion resistance, heat resistance, high pressure resistance and wear resistance.
|
|
|
|
|
|
Brand: PartnerFilter
Model: SO-611PLF3
Filter type: High-flow Aviation Separator Coalescer Filter
Length: 11 inches
Outside Diameter: 6 inches
Inside Diameter: 3.5 inches
End Caps: Carbon steel
Filter material: Pleated Paper, Teflon
Series: SO--636VA, SO-644PLBZ, SO-656V, SO-623VA more
|
|
SO-611PLF3 parker velcon separator cartridge is used as the second stage in the filter/separator container,its mainfunction is to repel coalesce water droplets produced by the first stage filter element while allowing hydrocarbon fluids to pass through,the water droplets sink into the filter/separator tank and are not carried downstream,all particle filtration is done by the first stage coalesce filter element.
|
|
|
|
|
|
Brand: PartnerFilter
Model: busch vacuum pump oil mist separator
OEM Ref: 0532 140 157, 0532 000 509
Filtration precision: 1um, 3um, 5um, 10um, 20um ……
Filter materials: fiber cotton, filter paper, stainless steel wire mesh
End cap material: Carbon Steel & Stainless Steel & Aluminum & Nylon & NBS
Temperature range: -4°F~212°F
Working medium: hydraulic oil
O-ring material: fluorine rubber, nitrile rubber
Series: 0532 140 151,0532 140 152,0532 140 153,0532 140 154more
|
|
0532 140 157 Busch Vacuum Pump filter element is used to filter impurities in the oil, oil and gas separation and filtration. Clean the vacuum pump, improve the quality and utilization of the oil, reduce the loss of the vacuum pump, and provide a good working environment for the vacuum pump.
|
|
|
|
|
|
Brand: PartnerFilter
Model: 96541600000 Oil Separator Filter
Type: Becker Separator Exhaust
Particles of oil separator: ≤0.1μm
Accuracy: 1μm-99μm
Working pressure: 0.8-1.2Mpa
Material: Paper、Glass Fiber、Fiber Cotton Series:96541300000,96541500000,96541600000,96540900000 more
|
|
96541600000 Separator Exhaust Becker Vacuum Pump Filter is used to prevent the escape of oil and oil vapors while removing oil from the exhaust gases of vacuum pumps. Prevent dirt and dust from entering the engine, improving efficiency and life. The manufacturing material adopts extremely high quality filter cotton core.
|
|
|
|
|
|
Brand: PartnerFilter
Model: P-CE03-595 oil filter
Filter Type: Air Oil Compressor Separator Filter
Filter materials: Carbon Steel
Usagematerial: Fiberglass
Filter Efficiency: 99.99%
Oil contained: 3ppM
Filtering precision: 0.1Micron
Series: PS-CE03-517,P-CE03-596,P-CE03-578,P-CE03-595 more
|
|
P-CE03-595 air oil separator is used to eliminate oil, water and dirt in the air or gas. It belongs to the category of coalescing separation filter elements and is used to treat oil mist particles in the air. P-CE03-595 can separate oil mist particles as small as 0.01 microns and has excellent performance and precision.
|
|
|
|
|
|
