Introduction: PartnerFilter manufactures 2903 7525 00 spin-on oil filter element with ultra-fine glass fiber composite filter material from HV Company of the United States or pure wood pulp filter paper of Ahlstrom Company of South Korea to filter out solid particles,impurities and oil deterioration in lubricating oil to protect the main engine and other running parts.
Structural diagram： All the solid particles above 3μm in the output air of the compressor can be filtered out,and the extremely small oil-water gas solution of about 0.01-1μm is condensed into larger oil droplets when passing through the filter element, and accumulates at the bottom of the filter element, and then passes through the filter element.The oil return pipe in the bottom recess of the filter element siphons back to the lubrication system so that the compressor discharges more pure,oil-free compressed air. ....
Performance parameters： In the compressor system,the oil filter 2903 7525 00 must be filtered periodically to remove contaminants that may enter the compressor and damage the equipment.This is done by installing a lubricating oil filter,either cartridge or rotary,and then ensuring that all the oil is cleaned as it passes through the filter. | Item | Value |
|---|
| Filtration Media..... | 10μm | | Filtration.... | β 1000 = 10 µ | | Size | OD3.82"*L8.35" | | Thread | 1" x 12 UNF | | Bypass Valve Opening Pressure.... | 2.5 bar | | Seal..... | Viton | | Gasket | Buna O-Ring | | Center Tube | Corrosion Resistant Steel.... |
Quality advantage： 2903 7525 00 oil separator cartridge filtration is in the 5-25 micron range (depending on the application),again the deposition of oil-borne contaminants over time (similar to oil separators),which causes the differential pressure of the oil filter to increase to a point where it must be replaced to continue to properly filter the compressor oil. We make 2903 7525 00 separator oil filter is Beta grade. Excellent filtration performance. The Beta X = 1000 number means that for every 1000 particles of size x in the fluid, on average only one particle will pass through the filter.
PartnerFilter oil filters are made from the highest quality materials and processes. Specific filtration levels of 2903 7525 00 oil filter cartridges are achieved through the exclusive use of advanced filtration media and consistent surface area control,achieved through strict maintenance of fold number and depth.The positive seal obtained by plasticsol and epoxy encapsulation prevents leakage.The use of Viton seals in which synthetic oil applications are typical.
Application: 2903 7525 00 oil filter cartridge is widely used different industries’ air compressor system: 1. Metallurgy: It is used for the filtration of the hydraulic system of rolling mills and continuous casting machines and the filtration of various lubricating equipment. 2. Petrochemical: Separation and recovery of products and intermediate products in the process of oil refining and chemical production, oil field injection well water and natural gas particle removal filtration. 3. Textile: Purification and uniform filtration of polyester melt in the drawing process, protection and filtration of air compressors, degreasing and water removal of compressed gas. 4. Electronics and pharmaceuticals: pretreatment filtration of reverse osmosis water and deionized water, pretreatment filtration of cleaning solution and glucose.
Notes: Apply lubricating oil to the gasket surface first before installing the 2903 7525 00. The mixed use of inferior lubricating oil and unmatched lubricating oil will accelerate the formation of carbon deposits and shorten the service life of the lubricating oil filter element.
PartnerFilter also offers a full range of replacement filter elements: ATLAS COPCO Filters INGERSOLL RAND Filters SULLAIR Filters COMPAIR Filters FUSHENG Filters LIU-TECH Filters MANN Filters Other types are available on request
|
