Oil purifiers
PartnerFilter is specialized in kinds of oil purifiers of Hydac,Leemin and PartnerFilter brand oil purifiers.Contact us at artnerfilter@outlook.com.
|
|
|
Brand: PartnerFilter
Model: OFU10P2N2B05B
Oil purifier type: Mobile
Max. flow rate: 100 l/min
Filtration accuracy: 1-40 μmor customized as operation
Operating pressure: 10 bar max.
|
|
PartnerFilter makes OFU10P2N2B05B Filter Pump Transfer Unit replacementwhich is a mobile oil service unit and widely used to filter oil when filling systems and when transferring hydraulic and lubricating fluids in different industries.
|
|
|
|
|
|
Brand:PartnerFilter
Model:LUC/A/B-63 x 10
Flow rate:63L/min
Micron:10µm
Seal:Viton
Initial △P:<0.02MPa
Filtration type:3 levels
Series:LUC/A/B-16x*-#LUC/A/B-40x*-#LUC/A/B-100x*-# more
|
|
The LUCLUCALUCB series oil filter trolleys replacement produced by our company not only have reliable performancecompact structurebeautiful appearanceconvenient maintenance and usebut also have the advantages of high precision and low noise.According to different needsyou can freely choose among 3 5 10 20 30umand you only need to replace the filter element with different filtration precision to achieve the filtration effect of different precision.All technical indicators of the oil have no effect.
|
|
|
|
|
|
Brand:PartnerFilter
Model:LUCD-63 x 10
Flow rate:63L/min
Micron:10µm
Seal:Viton
Initial △P:<0.02MPa
Filtration type:3 levels
Series:LUCD-40x*LUCD-63x*LUCD-100x* more
|
|
LUCD series oil filter cart is a new type of movable cart filter unit developed by our company.It has the performance and features of a TUC desktop oil filter unit. It can be flexibly used in different hydraulic systems to inject new oil to filter and regularly filter pollutants in the medium.It has no impact on various technical indicators of the oil.It can better help you deal with the pollution of the oil system and prolong the hydraulic system.The service life of components ensures the normal operation of the system.
|
|
|
|
|
|
Brand:PartnerFilter
Motor power:2.2KW
Working temp.:0~80℃
Flow rate:50L/min
Viscosity: ≤700(cSt)
Power supply:380V×3φ/50Hz
Micron:βx=1000
Model:PFC 8300-50-YV
Series:PFC8300-400 PFC8300-100-YV more
|
|
PFC8300-50-YV new style oil purifier is a new generation product,it is redesigned and readjusted on the whole structure.On the basis of maintaining the basic characteristics of the original productwe improve the overall strength and layoutand also increase the variety of functionswhich greatly improves the use safety and practicability of the product.
|
|
|
|
|
|
Brand:PartnerFilter
Model:LYC-100J
Flow rate:100L/min
Micron:3-40μm
Working temp.:25~80℃
Viscosity: 10-120cSt
Motor power:2.2KW
Power supply:380V×3φ/50Hz
Series:LYC-50JLYC-150J more
|
|
This machine has five filtration systems combining precise filtration and dewatering two functions into one efficient.The introduction of the US "coalescing separation" technology for dehydrationwhich has high efficient dehydration especially is adapted to the large amount of water separation from oil dehydration ability is far better than the centrifugal methodyou can get rid of all of the oil-water emulsion medium structure;by filtration particle filtration systemthe cleanliness of the medium can be controlled in a stable state of the system requirements to ensure the cleanliness;the oil does not change the physical and chemical propertiesto extend the service life of the oil;energy small low operating costs;excellent system configuration continuous strong performance for online operation.
|
|
|
|
|
|
Brand:PartnerFilter
Model:ZLYC-100
Flow rate:100L/min
Micron:3-20μm
Rated vacuum:≤-0.095
Water content:5-30ppm
Air content:≤0.2%
Power supply:380V×3φ/50Hz
Series:ZLYC-150HEP100 more
|
|
The vacuum dehydration oil purifier can effectively remove water in various states from the oiland can also remove air and various volatile substances from the oil.
Its operation principle is that different liquids have different saturation vapor pressure.At a temperature of 70 ℃and water at about 30000Pa pressure begins to boiland the oil in the low pressure of 5Pa to boiling.At the same temperatureoil saturation vapor pressure is much lower than water.Thereforethe oil in the liquid by vacuum pressure lowered to below the saturation vapor pressure of waterthe oil in water will dramatic gasificationin the form of vapor from the oil spill.
|
|
|
|
|
|
