Introduction: RSCP100-20EPP parker water cartridge filter is used in water fluids to efficiently remove impurities such as tiny particles and bacteria in the water fluids. The cleaning and filtration efficiency is as high as 99.8%, ensuring the original quality attributes of the water fluids. It is a high-efficiency microporous pleated water filter type.
Filter Material: RSCP100-20EPP parker water cartridge filter manufacturing materials are made of high-quality, safe and environmentally friendly filter membranes, and imported non-woven fabrics or mesh fabrics are used as the support layer, with full batch material traceability. The filter housing, center rod, and end caps adopt hot-melt welding technology without using any adhesives, additives, or lubricants, and without any fiber shedding.
.....
Technical specifications: • Filter Material: Pleated Fiberglass, Pleated Deep Polypropylene (PP), MBPP • Maximum pressure drop: pleated fiberglass 4.0bar, pleated deep polypropylene (PP) 3.4bar, MBPP 1.03bar • Maximum temperature: wrinkled fiberglass 121℃, deeply wrinkled polypropylene (PP) 82℃, MBPP 65℃ • Recommended maximum filtered water flow rate: 660L/min for 20-inch filter, 1300L/min for 40-inch filter, 1900L/min for 60-inch filter • Filtration precision: 0.1μm, 0.22μm, 0.45μm, 1μm, 3μm, 5μm, 10μm, 20μm, 50μm. • Gasket: silicone rubber, ethylene propylene rubber, nitrile rubber, fluorine rubber • Center pole: polypropylene • Support/Diversion Layer: Polypropylene (PP) • Sealing material: EPDM, BNR • End cap: fiberglass reinforced polypropylene • Filter element surface: PP melt-blown, melt-blown fine lines, melt-blown grooves, melt-blown embossing
Material flow characteristics: RSCP100-20EPP parker production process is environmentally friendly, pollution-free and leak-free. 100% integrity tested during production, manufactured, rinsed, tested and packaged in a clean room.
.....
RSCP100-20EPP Advatage Features: • High-quality filter material and hot-melt bonding process, high cleanliness, no adhesive added, no pollution to water quality. • Deep groove folding design increases the filtration area and the pressure drop is significantly lower than ordinary filter elements • Large diameter design increases the anti-fouling properties of the filter element, prolongs service life and reduces usage costs. • The surface fiber structure is strengthened to prevent the filter material fibers from falling off. • High-strength rigid external support enhances the filter element's ability to withstand pressure, making it ideal for harsh conditions and demanding applications with repeated cleaning. • Fully sealed interface design reduces the risk of side flow and ensures the tightness and reliability of filtration.
|
