Coalescer and separator
PartnerFilter produces kinds of brands Coaleser Separator Cartridges,PECO,FACET,FAUDI,PARKER&Velcon brands replacement.For detailed filters,contact us
|
|
|
Brand: PartnerFilter
Model: AC718P4D Parker Velcon
Filter type: Coalescer Filter Cartridge
Length: 18.0 inches
Inside Diameter: 2.6 inches
Outside Diameter: 6.3 inches
Carton Weight: 27.0 pounds
Filter construction: Pleated layers
Function: Water Absorbing
Maximum operating temperature:250°F
Water capacity: Ranges from 2 to 4 quarts
|
|
AC718P4D coalescer filter can well Remove Water and Dirt from Oils Fuels and Gases.The outer media layer filters out siltrust and other particulate contaminants.The inner layers absorb water and chemically bond it so that no water will release downstream.
|
|
|
|
|
|
Brand: PartnerFilter
Model: FO718 PL25
Filter type: Coalescer Filter Cartridge
Length: 18.0 inches
Inside Diameter: 2.6 inches
Outside Diameter: 6 inches
Collapse strength:75 psi
Maximum operating temperature: 250°F (121.1°C)
Filter construction: Pleated layers
Application: Water Liquid Absorbing
|
|
PartnerFilter makes FO718 PL25 coalescing filters replacement and the FO series pleated paper filter provides a cost effective solution for removal of solid particulate contaminants in fuel and industrial fluids with high efficiencylong life to absorb the water in oil and gas.
|
|
|
|
|
|
Brand: PartnerFilter
Model: ST643FF-5 separator cartridge
Type: oil separator filter
Material: Teflon
Sizes: OD6*L43”
Flow direction: Outside to inside
Cleanable and reusable: Yes
Maximum operating temperature: 240°F
|
|
ST643FF-5 oil separator cartridge for the oil or fluid operationit is essential that they are free from particulate contamination and free water.If the fluid does not meet the required cleanliness standardsfouling and corrosion of the equipment downstream may occurleading to expensive maintenance costs and reduced component life.A separator is a device for separating immiscible liquids or liquids from a gas stream.
|
|
|
|
|
|
Brand:PartnerFilter
Model: SD-718
Filter type: Cartridge
Size: Standards
Application: Transformer oil
Function: Remove dissolved water
|
|
SD-718 cartridge can remove dissolved water from transformer oil and reduce moisture in transformer oil to <10ppm without heat & vacuum specifically developed for dehydrating oil to be used in transformers SD-718 series cartridges can help utilities reduce expenses and increase efficiency when processing oil.
|
|
|
|
|
|
Brand:PartnerFilter
Filtration accuracy:0.5μm
Sizes:6 1/4*18”
Model:AC 7181/2
Filter Construction:Pleated
Application: Oil and gas industry
|
|
The coalescer AC 7181/2 is designed with a filtration structure to remove water and dirt from hydrocarbons and other oils as well as gases. The outer dielectric layer filters out silt and other granular contaminants. The inner layer absorbs the water and chemically combines it so that no water is released downstream.
|
|
|
|
|
|
Brand: PartnerFilter
Model: CAA43-5SB
Type: Facet Coalescer Filter Cartridge
Sizes: OD6”*L45”
Seal: Viton
Filter material: Fiberglass
Mounting style: Screw base
End caps: Injection Moldedglass-filled Nylon
Series:CAA33,CAA28,CAA33,CAA38,CAA11,CAA14,CAA56 series more
|
|
Facet CAA43-5SB high flow coalescing filter cartridges are used to remove ultrafine solids and enhance water separation from jet fuel. The main advantage is balancing fluid flow and structural strength. Manufactured from a single piece of construction using various combinations of media, precisely arranged in multiple layers and pleats, wrapped around a coated perforated metal center tube, the coalescing cartridge is guaranteed for optimal performance.
|
|
|
|
|
|
Brand:PartnerFilter
Model: ST630FE-5
Type: Separator Cartridge
Seal: Buna-N
Filter material: Teflon
Sizes: OD6”*L30”
Flow direction: Outside to in
Max.operating temp.: 240°F (115 ° C)
End Caps: Corrosion Resistant Steel
Center Tube: Corrosion Resistant Steel
Series: ST630FE, ST633FB, ST633FD, ST636FB, ST636FD Series more
|
|
Facet ST630FE-5 separator uses teflon coated screen wrapped around an epoxy coated metal shelllock-seam foldedthen adhesive bonded to metal end caps with gaskets.
|
|
|
|
|
|
Brand:PartnerFilter
Model:SS644FD-5
Filter Type: Separator Cartridge
Seal: Buna-N
Filter material: Teflon Synthetic
Sizes:OD6”*L44”
Flow direction: Outside to in
End Caps: Corrosion Resistant Steel
Center Tube: Corrosion Resistant Steel
Series: SS644FE-5, SS644FF-5, SS648FD-5, SS648FF-5, SS656FB-5, SS656FF-5 more
|
|
PartnerFilter makes different types coalescer and separator with synthetic and teflon materialthe Facet SS644FD-5 synthetic separator cartridge feature a specially developed treated hydrophobic media. This media provides improved separation of fine water drops compared to standard Teflon screen. An ultrasonically seamed tube of the synthetic screen is placed around an epoxy coated metal shell
then adhesive bonded to metal end caps with gaskets.
|
|
|
|
|
|
Brand:
Brand:PartnerFilter
Model: I-62887TB
Filter Type: Coalescer Cartridge Filter
Seal: Buna-N
Length: 28.7 inches
Inside Diameter: 3.5 inches
Outside Diameter: 6 inches
Filter material: Fiberglass
End Cap Configuration: Threaded Base
Pressure differential rating: 75psid
Max.operating temp: 150-160°F (66-71°C)
Series: I62281, I62281TB, I62283, I62283TB, I62285TB, I62287 more
|
|
I-62887TB coalescer cartridge uses a multilayer pleated medium designed to provide superior on-site fouling capacity and has an efficiency of 0.4 micron.It’s a single-unit coalescer elementprovided with a threaded base and open endsas well as a combination of fiberglass media and pleated media.
|
|
|
|
|
|
