Filter Element
Hydraulic Oil Filter Elements,Air Compressor&ln-line Filters,air Filter element,water Filter element,contact us artnerfilter@outlook.com
|
|
|
Brand: PartnerFilter
Model: PFS1001ZMH13
Type: Oil Gas Coalescing Filter
Length: 247.7 mm
Outer Diameter: 69.9 mm
Inner Diameter: 24 mm
Carton Weight: 7.0 pounds
Filter Media: Fiberglass
End Caps: Stainless Steel
Maximum Differential Pressure: 50psid(3.4bard)
Clean Saturated Pressure Drop: 1.5psid(103.4mbard)
Coalescing Efficiency at 0.3 µm: 99.99%
Sealing Mechanism: open-ended(with gaskets/tie rod)
|
|
PFS1001ZMH13 PALL gas coalescence filters is used to removal oil, water, and dirt in air or gas. and is made of various composite materials and high area folded glass fiber media through special processes. It is a sturdy, inexpensive, and efficient filter.
|
|
|
|
|
|
Brand:PartnerFilter
Model: A910303
Series: Turbo-TOC Separator Filter
Length: 743.0 mm
Outer Diameter: 152.4 mm
Inner Diameter: 88.9 mm
Filter Material: Teflon
Seal: Buna-N
Maximum Temperature: 107℃
Micron Rating: 10.00 nominal
Collapse Pressure Rating: 75 PSID
Series: A910203, A910362, A910370, A910415, A910575 more
|
|
A910303 kaydon separator filter is designed for installation in vertical filters/separators. It can filter out solid particles and mechanical impurities, and can also remove emulsified water in the medium through demulsification and coalescence.
|
|
|
|
|
|
Brand: PartnerFilter
Model: NGGC-336 PECO Series
Type: Coalescing Filter
Length: 914.5mm
Outer Diameter: 114.3mm
Inner Diameter: 75mm
Filter Material: Glassfiber
End Caps: Galvanized Steel
Series: NGGC-336, NGGC-336-PL-01 more
|
|
NGGC-336-PL-01 PECO fuel gas coalescer filter is used to remove water, oil vapor and other contaminants from hydraulic fluid compressed air or natural gas lines.For gas filtration and coalescence separation in chemical plants, petrochemical plants, offshore sectors and power stations. High flow rate, low flow resistance and high dust holding capacity.
|
|
|
|
|
|
Brand: PartnerFilter
Model: HC628-01-CSP HILLIARD HILCO Filter
Type: Oil Gas Coalescence Separator Filter
Length: 735 mm
Out Diameter: 155 mm
Micron: 10
Media: Fiberglass
End Caps: Galvanized
Series: HC628-01-CSP HILLIARD HILCO Filter more
|
|
HC628-01-CSP HILLIARD HILCO separator filter main function separate oil-water mixtures, suspensions, emulsions, etc. Filter out solid impurities and coalesce to remove moisture from oil/oil gas. Prevents clogging of orifices in pneumatic controllers and reduces gas engine fouling.
|
|
|
|
|
|
Brand: PartnerFilter
Model: SO-436V5
Type: Oil Fluid Separator Cartridge Filter
Length: 24 inches
Inside Diameter: 3.5 inches
Outside Diameter: 4.5 inches
Carton Weight: 14.5 pounds
Construction: Teflon
Media: TCS
Seal Material: Buna-N
Series:SO-324V5,SO-613GS,SO-633VASN,SO-609V,SO-323V5 more
|
|
SO-436V5 Parker Velcon separator cartridge filter is used to remove coalesced water droplets and solid, hard impurities, clean hydraulic fluid, compressed air or natural gas and other oils. The material uses fiberglass layers, which have a particularly good coalescing effect.
|
|
|
|
|
|
Brand: PartnerFilter
Model: CC3LGA7H13
Type: Liquid Gas Coalescing Cartridge
Length: 29.30 inches
Outer Diameter: 2.80 inches
Inner Diameter: 1.50 inches
Seal Material: fluorine rubber ring, nitrile rubber
Filter Materials: glass fiber filter paper, stainless steel sintered mesh
Working Medium: hydraulic oil, emulsion, water-ethylene glycol etc
Series: CC3LG02H13, CC3LGA7H13, CC05LGH13, CC3LGB7H13more
|
|
CC3LGA7H13 liquid gas coalescing cartridge filter is used to oil and gas separator, hydraulic liquid fuel system. Separate oil-water mixtures, emulsions, suspensions, etc. Clean hydraulic fluids, compressed air or natural gas and other oils. Corrosion resistance, heat resistance, high pressure resistance and wear resistance.
|
|
|
|
|
|
Brand:PartnerFilter
Model:RSCP045-60NPP
Gasket:Buna
Filter type:High-flow
Sizes:OD6.4”*L60”
End Caps:Polypropylene
Filter material:Polypropylene
Center Tube:Polypropylene
Retention Ratings:99.98%@ 4.5 µmBuna
Maximum Temperature:176ºF (80ºC) @ 30psid (2.1bar)
Series:RSCP030-60NPP,RSCP100-60NPP more
|
|
RSCP045-60NPP high flow filter integrates advanced step folding technology and large diameter technology.The unique step folding method provides higher flow rate while ensuring high contaminant absorption capacity and pollutant retention efficiency of the product.A 60-inch filter can flow up to 500 gallons per minute.The inside-out flow of the fluid enables the filter element to have a higher fouling capacity and online life,so the RSCP045-60NPP is ideal for all kinds of fluid filtration.
|
|
|
|
|
|
Brand: PartnerFilter
Model: 0330R010ON
Filtration precision: 10um
Filter media: hydraulic oil, lubricating oil
Working Pressure: 500 PSI
Working temperature: -10℃-100℃
Filter material: Optimicron®
Sealing material: NBR (nitrile rubber)
Series: 0330R010ON-V,0330R010ON-KB,0330R020ON-V,0330R020ON-KB more
|
|
0330R010ON Hydac hydraulic filter is used to improve oil cleanliness and equipment operation efficiency. To solve the problem of oil pollution in hydraulic and lubrication systems. 0330R010ON's core function is improve quality and filter out solid particles, colloidal substances, moisture and other impurities in the working medium.
|
|
|
|
|
|
Brand: PartnerFilter
Model: 0550R010ON
Type: oil hydraulic filter
Material: HV fiberglass, Ahistrom filter paper, stainless steel wire mesh
Filter media: hydraulic oil, lubricating oil
Filter accuracy: from 1, 3, 6, 12, 25 …um
Working temperature: -10℃-100℃
Pressure: 1.0Mpa, 2.0Mpa, 16.0Mpa, 21.0Mpa
Application field: hydraulic system, lubrication system
O-Ring: NBR, fluororubber
Series: 0240R010BN3HC,,0210R020BN4HC,0330R010BN3HC,0660R020BN3HC,1300R010BN4HC more
|
|
0550R010ON hydac oil filter is widely used in hydraulic systems, lubrication systems and other fields. Its main function is to filter out impurities and particles in the oil to ensure the cleanliness of the oil, thereby extending the service life of the oil and the normal operation of the system. It is an efficient, stable and reliable filter element.
|
|
|
|
|
|
